用途：
干式喷漆系统及排出漆雾系统
特性：
采用强弹性抗断裂的玻璃纤维以非织物方渐密式结构组成，阻力小，透风量大
可高温达120℃
进风面为绿色，出风面白风
不含硅
可压缩性，便于节省运费及储存空间
可切片或成卷供应
Uses:
The dry spray system and exhaust mist system
Features:
Using strong elastic fracture resistance of glass fiber non-woven side gradually close the structure, small resistance, large ventilation quantity
Temperatures up to 120 ° C
The inlet side of the green, the wind surface white wind
No silicon
Compressibility, easy to save on shipping and storage space
Can be sliced or coils
|
名称
name
|
单位
unit
|
G3
|
G4
|
|
平均捕捉率
Average capture rate
|
%
|
95
|
98
|
|
额定风量
rated airflow
|
M³/h
|
2500-6300
|
2500-6300
|
|
初阻
Initially resistance
|
Pa
|
7-40
|
14-60
|
|
风速
Speed of wind
|
m/s
|
0.7-1.75
|
0.7-1.75
|
|
容漆量
Plant holding capacity
|
G
|
3500-4700
|
3900-5050
|
|
厚度
thickness
|
mm
|
50-70
|
50-100
|
